Beacon Lights

Beacon lights are designed to create maximum visibility to reduce accidents on the road and in the workplace.

Ultra (Class 1) are commonly used on police, fire, ambulances and road commission vehicles. They are 4 times brighter than the High (Class 2) strobes and 10 times brighter than the Medium (Class 3) strobes.

High (Class 2) are commonly used on construction, maintenance and service vehicles. They are 2 1/2 times brighter than Medium (Class 3) strobes.

Medium (Class 3) are commonly used for indoor vehicles, such as forklifts, sweepers and floor cleaners.

LED have superior durability, shock resistance, and energy efficiency.

A
B
C
D
E
F
G
H
  Intensity Mount Voltage Amps Size (H x D) Part Number
(A) Ultra (Class 1) Permanent, Wire Leads 12-48 VDC 2.0 6" x 5.5" FLST-SC12-7
(B) High (Class 2) Permanent, Wire Leads, Short Lens 12-30 VDC 0.4 5" x 6.5" ST-256TSL-A
(B) High (Class 2) Permanent, Wire Leads, Short Clear Lens 12-30 VDC 0.4 5" x 6.5" ST-256TSL-C
(C) High (Class 2) Permanent, Wire Leads, Tall Lens 12-30 VDC 0.4 6.7" x 6.5" ST-256TCL-A
(D) High (Class 2) Magnet, Cigarette Plug, Short Lens 12-30 VDC 0.4 5" x 6.5" ST-256TSLM-A
(E) High (Class 2) Magnet, Cigarette Plug, Tall Lens 12-30 VDC 0.4 6.7" x 6.5" ST-256TCLM-A
(F) Medium (Class 3) Permanent, Wire Leads 12-80 VDC 2.7 3.8" x 5.6" PR-7314A
(G) Medium (Class 3) Magnet, Cigarette Plug 12-80 VDC 2.7 3.8" x 5.6" PR-7314A-MG
(H) Low Magnet, Uses 2 "D" Batteries N/A N/A 5" x 4.25" NAS-PSLM2-A

Accessories

A B C
Description Voltage Part Number
(A) Vacuum-Magnet, Cigarette Adapter, For use with PR-7620A, PR-7625A and PR-7512A 12-48 VDC PR-MKS4000
(B) LED Strobe Pigtail, Powers 40 LED Lamps, 850 FPM, Potted 9-16 VDC PT-LED/ST
(C) LED Quad Flash Pigtail, Powers 16 Lights, Potted 12 VDC PT-LED/QUAD

Halogen have replaceable bulbs.

A
B
C
D
  Intensity Mount Voltage Amps Size (H x D) Part Number
(A) Ultra (Class 1) Permanent, Wire Leads 12-48 VDC 2.0 4.5" x 5.5" FLST-SC12-4
(B) High (Class 2) Permanent, Wire Leads 12-24 VDC 2.0 4.25 " x 5.5 " STAR 240SFQ
(C) High (Class 2) Permanent, Wire Leads 12-24 VDC 0.9 4.5" x 5.5" NAS-DFS625-A
(A) Low Permanent, Wire Leads 12-36 VDC 0.25 3 5/8" x 4" FLST-SC20-4
(A) Low Permanent, Wire Leads 12-36 VDC 0.5 4" x 4" FLST-SC40-4
(D) Low Magnet, Cigarette Plug 12 VDC 0.5 4" x 4" FLST-SC4041-12V
Flashing LED Lights - Amber

Amber

Description Size Voltage Flashes/Min Part Number

High Powered LED, No Control Box, Can be

Wired to Alternate, Grommet Included,

Will fit standard 4" round Stop/Tail/Turn hole

4" Diameter 12-24 VDC 18 Quad Flashes NAS-LEDQR-A

High Powered LED, No Control Box, Can be

Wired to Alternate, Grommet Included,

Will fit standard oval Stop/Tail/Turn hole

6 1/4" L x 2 1/4 H" Oval 12-24 VDC 18 Quad Flash NAS-LEDQO-A

LED Flashing Light, Polycarbonate Housing

Kit, Includes Grommet, Light and Pigtail,

Will fit standard oval Stop/Tail/Turn hole

6 1/2" L x 2 3/8 H" Oval 12-24 VDC 72 Quad Flash TT-607101-02

High Powered Grill Light, Features

Two 6 LED Lamps with 10' of Cable

Between the two Heads, Mounting

Clips for Installation, Class 2

1.25"H x 7"L x 1.25"W

(each lamp size)

12 VDC GLED8000-A

Green and Amber

Description Size Voltage Flashes/Min Part Number

Green and Amber, LED, Recessed Grommet

Mount, Includes Grommet, Light and Pigtail,

Alternating or Synchronized Flash Patterns

6.5" L x 2.25" H Oval 12-24 VDC 284 Quad Flash BY-SL66AG

Green and Amber, LED, Ultra Thin, Clear

Lens, Permanent Mount, Includes Self

Adhesive Tape, 0.65 Amps, 23 Flash Patterns

4.38" L x 1.18" H 12-24 VDC ------- BY-8892250

Green, LED, LED, Ultra Thin, Clear Lens,

Permanent Mount, Includes Self Adhesive

Tape, 1 Amp, 23 Flash Patterns

5.14" L x 1.18" H 12-24 VDC ------- BY-8892209

Green and Amber, LED, Ultra Thin, Clear

Lens, Permanent Mount, Includes Self

Adhesive Tape, 1 Amp, 23 Flash Patterns

5.14" L x 1.18" H

12-24 VDC ------- BY-8892210

Can't Find the Lighting Product That You Need?

We stock Preco, Federal Signal, Target Tech, Star, North American Signal, Truck Lite, Grote and Superior Signals.
